Small Vehicle

Frequency Range	20 kHz to 170 kHz
Reaction Time	10ms
Supply Voltage	230V AC
Voltage Tolerance AC	+10%/-15%
Power Consumption	4.5VA
Output Relays	240V/5A
Operating Temperature	-20°C to +65°C
Storage Temperature	-40C to +85C
Presence Time	Permanent
Sensitivity	Adjustable in 4 Increments
Loop Inductance	Total loop plus connection wiring:50H to 1000H/Ideal is 100H to 300H
Loop Connection Wiring	Maximum length 20 meters, twisted at least 20 times per meter
Size of Housing	78x40x108 (mm)
